Power Rating - KVA | KVA | |
---|---|---|
Battery Backup | 12V/__AH SMF Batteries *___ no’s | |
Battery Rack | MS Battery rack | |
DC system Voltage | ___ VDC | |
Backup time | ___ Minutes | |
Input | Nominal Voltage | 380/220, 400/230, 415/240, Vac (3 Phase, 4 - Wire plus Ground) |
Voltage Range | ± 20% | |
Current Harmonic Distortion | < 3% (with optional rectifier or filter, full load) | |
Frequency | 50 or 60 Hz ± 5% | |
Output | Voltage | (3 Phase , 4 - Wire) |
220, 230, 240, Vac (1 Phase, 2 - Wire Plus Ground)* | ||
Voltage Harmonic Distortion | ≤ 3% (linear load) | |
Voltage Regulation | ± 1% (Static) | |
Frequency | 50 or 60 Hz 0.5% | |
Frequency Regulation | ± 0.01% (interior oscillation); ± 1% (Synchronized) | |
Overload Capability | ≤ 110%; 60 minutes; 110-125%; 10 minutes; 126-150%; 1 minute | |
Waveform | Pure Sine Wave | |
Crest Factor | ||
Output Voltage Dynamic Regulation | ± 5% (For 0 ~ 100% Load Variation) | |
Voltage Symmetry with 100% unbalanced load | ± 1% | |
Batteries | Type | SMF |
Backup Time | As per Offer | |
Rated Battery Voltage | 120V DC (36 – 360)V DC | |
Rectifier Output | Ripple | < 1% |
Inverter Output | Static Stability | ± 1% |
Dynamic Stability | ± 5% in 5ms | |
Inverter Efficiency | 93% | |
Operating Temperature | 0° to 40°C | |
Relative Humidity | 95% (Non Condensing) | |
Noise | 53/60db at 1 meter | |
Protection Rating | 1P 20 | |
Efficiency | 92% | |
Compliance | Safety EN 62040-1 EMC EN 62040-2 | |
Protection Rating | Output short circuit | |
Battery Low Tripping | ||
D.C. Over Voltage & main over voltage Battery & Inverter by HRC Fuse link & MCB Input MCB/Output MCB Output over load Output Over Voltage | ||
Indications | Status Indication for the following: Main ON, Battery ON, Inverter ON, Battery Low, Over Voltage, Inverter Over load | |
Alarm with Indications | Battery Low | |
Metering | D.C. Volts/Output A.C. Volts, Input AC Volts, Frequency. LCD Display | |
By-pass | Manual By-pass provided (For Maintenance) |
