ISOLATION TRANSFORMER

ISOLATION TRANSFORMER



Product Description:

  • In order to meet rising demands of our clients, we are offering Isolation Transformer to our clients. There is an excellent range of these transformers available with us. These are critical in power supply chain and are able to work for 24/7 in several cases. These transformers have excellent quality and are highly efficient. Considering several benefits of these transformers, the experts have developed these in innovative manner and these are able to offer best and superior performance for years.

Features:

  • Portable design
  • Durable standard
  • Energy efficient

Technical Specification for 3 phase step down Isolation Transformer


Sl No. PARAMETERS SPECIFICATION
1 TYPE Dry Type
2 MAKE FAITH
3 TYPE OF COOLING Natural Air Cooled
4 CAPACITY 1KVA - 1000KVA
5 PRODUCT Isolation Transformer
6 CONSTRUCTION Core Type Construction
7 INPUT VOLTAGE 415V, +/- 1%
8 OUTPUT VOLTAGE 415V +/- 1% (Ph-Ph)
115V (Ph-N)
9 K RATING NORMAL
10 MAXIMUM OUTPUT CURRENT 80 Amps
11 INPUT FREQUENCY 50 Hz +/- 3%
12 IR VALUE >1000MΩ
13 DI ELECTRIC STRENGTH 2.5 KV for 60 Seconds
14 LEAKAGE CURRENT <5 milli Amps
15 IMPEDENCE VOLTAGE 3-4 %
16 REGULATION 3-4 %
17 LOSS PER KG < 1.5 Watts at 1.7 Tesla
18 NO LOAD LOSSES < 1.2 %
19 LOAD LOSSES < 1.8 %
20 TEMPERATURE RISE <99° exclusive of ambient temperature
21 EFFICIENCY >97%
22 DUTY Continuous
23 CLASS OF INSULATION Class ‘H’
24 SERVICES Indoor Application
25 METHOD OF WINDING Multiple Parallel to Reduce Skin Effect
26 DEGREE OF IP P-21
27 DIMENSION AND WEIGHT Will be given after order confirmation
28 STANDARD IS : 2026
29 WINDING MATERIAL Aluminum Wound / Copper Wound
30 VECTOR GROUP Dyn-11
